Aspen Avionics: EWR50 Evolution Weather Receiver

EWR50 Evolution Weather Receiver

Overview
Features
Specifications
Images

$2,495 MSRP

The Evolution EWR50 is the lowest cost certified weather receiver available. The EWR50 features plug-and-play compatibility with Evolution Hazard Awareness (EHA) (available separately) integrating weather, traffic and terrain hazard information into your primary field of view.

EHA capability can be integrated into one, two or three unit Evolution EFD and MFD installations. The EWR50 provides datalink weather displays simultaneously on up to three displays.

Our current release schedule can be found here: Evolution Availability

Get the latest news via our RSS-enabled Evolution Tracking

Features, specifications and images for this product may not be representative of the actual product.

Features include:

XM^TM Satellite Weather compatible
Display datalink weather on up to three displays with one receiver
Evolution Hazard Awareness information sheet [pdf]

EWR50 Display Assembly

General Specifications:

Part Number	920-00008-001
Dimensions	7.8" x 6.46" x 1.35"
Weight	1.4 lbs

Operational Specifications:

Operating Temp:	-20°C to +55°C
Storage Temp:	-55°C to +85°C
Max Un-Pressurized Operating	55,000
Cooling	None required
Max Humidity	95% at 50°C
Input Voltage	+11 to +32 Volts DC
Nominal Current	0.12/0.22 Amps (28v/14v)

I/O Specifications:

RS-232 Interface

Certification Specifications:

Environmental

RTCA DO-160E

EWR50

Click on an image below for a larger image window.
